Key Features

• High 3450mAh typical capacity for extended energy delivery
• 10A maximum continuous discharge capability
• Button top terminal for compatibility with spring-contact devices
• High energy density lithium-ion chemistry
• Stable CC-CV charging characteristics

Overview

The Panasonic NCR18650GA Button Top is a high-capacity lithium-ion cell designed for applications that require long runtime and dependable discharge performance. With a typical capacity of 3450mAh and a continuous discharge rating of up to 10A, this cell delivers consistent output while maintaining excellent thermal and electrical stability. The button top design allows compatibility with devices requiring a raised positive terminal.

Applications / Uses

• Rechargeable battery pack assemblies
• Portable power systems
• Energy storage solutions
• Professional electronic equipment
• Custom lithium-ion battery builds

SPECIFICATIONS

Manufacturer	Panasonic
Model	NCR18650GA
Size	18650
Positive Terminal	Button Top
Nominal Capacity	3450mAh (Typical)
Continuous Discharge Rating	10A Maximum Continuous
Nominal Voltage	3.6V
Maximum Voltage	4.2V
Discharge Cut-Off Voltage	2.5V
Protected	No
Rechargeable	Yes
Approx. Dimensions	18.5mm × 66.8mm
Approx. Weight	48.2g
Data Specification Sheet	Panasonic NCR18650GA Datasheet
